IPC-FE554-M

5MP WizMind Fisheye Network CAMERA

SKU IPC-FE554-M Category NETWORK CAMERAS Tag BLUE|LINE

5MP, 1/2.7” CMOS image sensor, low illuminance, high image definition
Outputs max. 5MP (2592 x 1944) @25/30 fps
H.265 codec, high compression rate, ultra-low bit rate
ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
120dB WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
Intelligent detection: Intrusion, tripwire, people counting in area
Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic
12V DC/PoE power supply, easy for installation
IP67, IK10 protection
Heat map for people counting. You can adjust the number of people, time threshold to generate a heat map, which can be exported.

Additional information

Image Sensor	1/2.7'' Progressive Scan CMOS
Max. Resolution	2592 × 1944
ROM/RAM	128 MB/512 MB
Minimum Illumination	0.006 Lux@F2.0 (Color, 30IRE)
Video Bit Rate	H.264: 3 kbps–8192 kbps H.265: 3 kbps–8192 kbps
WDR	120 dB
Lens Type	Fixed Lens
Lens Mount	M12
Max. Aperture	F2.0
Storage	FTP; SFTP; Micro SD card (support max. 256 G); NAS
Power	DC 12V/PoE
Protection Grade	IP67; IK10
Casing	Metal
Dimensions	62.0 mm × Φ110.0 mm (2.44" × Φ4.3")
Net Weight	387 g (0.9 lb)
Gross Weight	502 g (1.1 lb)
