6 MP AcuSense Fixed mini Dome Network Camera
| Camera Resolutions | |
|---|---|
| Camera Style | |
| Lens Type | |
| Image Sensor | |
| Max. Resolution | |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: -30° to 30°, tilt: 0° to 75°, rotate: 0° to 360° |
| Focal Length & FOV | 2.8 mm, horizontal FOV 104.3°, vertical FOV 55.9°, diagonal FOV 123.8° 4 mm, horizontal FOV 83.7°, vertical FOV 43.0°, diagonal FOV 100.3° |
| Max. Aperture | |
| Lens Mount | |
| Video Bit Rate | |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| WDR | |
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Power | 12 VDC ±25%, 0.45 A, max. 5.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection PoE: 802.3af, Class 3, 36 V to 57 V, 0.18 A to 0.11 A, max. 6.5 W |
| Material | Base: aluminum, cover: plastic |
| Protection | |
| Dimension | Ø110 mm × 57.4 mm (Ø 4.3" × 2.3") |
| Weight | Approx. 615 g (1.4 lb.) |
